Kiosk 15 inch Industrial Touch Screen PC High Brightness VGA Intel® Atom™ D2550

Name: Kiosk 15 inch Industrial Touch Screen PC High Brightness VGA Intel Atom D2550
Brand: AXNEW
Price: 300 USD

China Kiosk 15 inch Industrial Touch Screen PC High Brightness VGA Intel® Atom™ D2550 wholesale

Place of Origin : Shenzhen China

Brand Name : AXNEW

Model Number : AXD-15PPC-A1

MOQ : 5 pieces

Price : US$300-500/PCS

Packaging Details : 2 Pcs /Carton with firm foam

Delivery Time : 10-15 working days

Payment Terms : T/T, Paypal, Western Union

Supply Ability : 1000 pieces/month

Certification : CE ROHS

Application : Advertising|industrial|Kiosk

Feature : HD|slim

Input signal : VGA

Monitor type : Backlight|Touch Screen|Resistive

Panel Type : TFT

Power Input : 12V

Product name : Touch Panel PC

response time : 10ms

Contact Now

Kiosk High Brightness 15 inch VGA Industrial Touch Panel PC Intel® Atom™ D2550

IP65 Stainless Steel Fanless 15" Industrial High Brightness Panel PC with Intel® Atom™ D2550

which is widely used to mount into the Automatic equipments, Gas Station ,Advertising , vending embedded system, Kiosk application etc.

Quick Details:

Model: AXD-15PPC-A1
Screen Size:15’’
Screen format: 4:3
Display Resolution(pixel):1024X768
Contrast Ratio:600:1
Brightness:350cd/m^2
Storage temperature : -20℃~70℃
Touch Type: Resistive Touch screen
Power Input: DC 12V
Product status: Stock

Features and Advantages

1. Fanless Design; Ultra Slim and Compact Mechanical Design
2. High Luminance LCD Panel
3. Intel® Atom™ D2550 1.86GHz Processor
4. 15 " VXGA 1024 x 768 Resolution Color TFT LCD Display
5. Fully IP65 Waterproof Compliant Stainless Steel Chassis
6. Supp orts Wide Range DC Power Input (12V)
7. Intel® 8G SSD Compatible
8. Wake-on-LAN functionality for targeted centralized startup via a network

Specifications datasheet

Panel PC information
Model Number	AXD-15PPC-A1
Model Number	15’’ Touch panel pc
Case/Bezel Color	Black
TFT Type	Industrial LCD with LED backlight
Aspect ratio	4:3
Touch Panel	Industrial 4 wire Resistive Flat Screen
Touch response time	10ms (typical)
Optimal (native) Resolution	1024x768
LCD panel Pixel pitch	0.296 x 0.296 mm
LCD panel Colors	16.2 million
LCD panel Brightness	350 cd/m2
LCD panel Response Time	8ms
Contrast Ratio	600:1
Viewing Angle ( Wide )
Horizontal (left/right)	±70° or 140° total
Vertical (up/down)	80°(up), 80°(down) or 160° total
CPU	Intel® Atom™ D2550 1.86GHz
storage	8 G SSD ( optional)
Serial Ports	6 x COM ports
USB Ports	4 x USB
LAN	1 x LAN RJ-45 connector
DC Power In	1 x 4-pin connector
Video Port	2X Audio
Other Ports	2x LAN, 1XVGA,1xHDMI,1XLPT
Internal Sockets & Connectors	1 x Compact Flash socket (reserved for OEM project)
Power Specification	DC 12V
Working Environment
Temperature	Operating: 0°C to 50°C ;Storage -30°C to 65°C
Operating Humidity	5 ~ 90% RH @40°C (non-condensing
Vibration	5 ~ 500Hz, 3Grms Random (with CF/SSD)
Dimensions
Mounting Type	Embedded Installation
Mechanical dimensions	355.8 x 287.3 x 62.4 mm
Weight (Net)	7.5 kgs/ piece
Drawings	Please contact us for details
